DESCRIPTION

Basic Info.

Number of Blade	Three Blade
Rotating Shaft	Horizontal
Stress Way of Blade	Resistance
Power	＜10kW
Phase	Single-Phase
Certification	CE, ISO, TUV
Color	White , Red , Green ,Brown or to What You Prefer
Generator Material	Permanent Magnetic Levitation
Inverter	Pure Sine Wave
Grid	on Grid or off Grid
Tower	Free Standing or Guy Tied
Transport Package	Polywood Case
Specification	30kw
Trademark	ALLRUN
Origin	China
Production Capacity	1000sets/Month

Product Description

Horizon free standing tower on grid off grid 5kw 10kw 20kw 30kw wind power generator for home from Qingdao allrun new energy co., ltd
Allun wind turbine can start in a light wind. And in the bad environment, it can work safely, regardless of a furious storm, no needing special caring. It is ideal power source of the scattered inhabitants of the mountain area islands, poor signal transfer station, prairie farm, and fishing vessels.10KW wind turbine can be set to meet a family color television VCD, satellite receiver, electric fans, washing machines,refrigeratory and electric lighting.And it can also power for the office, the small factory and so on.

AR4.0-3KW

Power(w)	3000	Rated wind speed(m/s)	8
Rotor diameter(m)	4	Start-up wind speed(m/s)	3
Length of blade(m)	1.8	Range of working wind speed(m/s)	3-25
Material of blades and numbers	Glass Fiber Reinforced Plastic/5	Survival wind speed(m/s)	50
Number of blades:	3pcs	Output Voltage	AC48/96V/AC220V
Speed regulation method	Electromagnetic control	Stop method	Electromagnetic brake
Wind energy utilized coeffeicent	30%	Suggested supporting battery	8pcs 200ah
Range of working temperature	-45-60	Top weight (kg)	205

AR5.0-5KW

Power(w)	5000	Rated wind speed(m/s)	8
Rotor diameter(m)	5	Start-up wind speed(m/s)	3
Lengtht of blade(m)	2.2	Range of working wind speed(m/s)	3-30
Material of blades and numbers	Glass Fiber Reinforced Plastic/5	Survival wind speed(m/s)	50
Number of blades:	5PCS	Output Voltage	AC48v/96v220V/380v
Speed regulation method	Electromagnetic control	Stop method	Electromagnetic brake
Wind energy utilized coeffeicent	30%	Suggested supporting battery	18pcs12v100ah
Range of working temperature	-45-60	Top weight (kg)	285

AR6.2-10KW

Power(w)	10000	Rated wind speed(m/s)	10
Rotor diameter(m)	6.2	Start-up wind speed(m/s)	3
Length of blade(m)	2.9	Range of working wind speed(m/s)	3 -40
Material of blades and numbers	Glass Fiber Reinforced Plastic/5	Number of blades:
Number of blades	3pcs	Output Voltage	AC96v/220V/380v
Speed regulation method	Electromagnetic control	Stop method	Electromagnetic brake
Wind energy utilized coeffeicent	30%	Suggested supporting battery	18pcs12v150ah
Range of working temperature	-45-60	Top weight (kg)	300

Sound Data
Test position: 5kW Vertical Wind Turbine at 15m away from generator (average value of 3 point-rears, left, right)

Wind Speed (m/s)	3	4	5	6	7	8	9	10	11
Sound(dB )	18	22	23	23.9	26	30	31	32	33
Wind Speed (m/s)	12	13	14	15	16	17	18	19	20
Sound(dB )	33.5	33.5	34	34	34	34	34.5	34.5	34.5

System Design Service

We can design different system for customers according their request. For example, off-grid system , Grid-tie system, solar wind hybrid system or solar wind diesel generator system.

Off grid HAWT system

ON grid VAWT system

Hybrid wind solar system (, ob grid or off grid , and Genertaor optional)

Packaging & Shipping

1. Vertical wind turbine use inner foam protection outer Plywooden case .2. Tower with Foam package only.3. Controller invertor with inner carton box outer plywooden case.4. Pakage size and weight up to different turbine5. Shipping by sea with FCL LCL or by air.
If you have any request in package and shipping please tell our sales we will do according to your request.

1. What size do you produce ?

Allrun can produce from 150W to 300KW wind turbine, can supply parts or whole unit

2.which style do you produce ?

Allrun can produce both on grid and off grid, horizon style and vertical style.hybrid win dolar system . we can adjust to what you need

3. what the warranty ?

Allrun can offer 20 years warranty

4.what about the delivery ?

Allrun can delivery goods in 7days after payment , and also we can help you ship all over the world, you know we have our own shipping forwader .
